WALL MOUNTING ENCLOSURES・FLANGED PLASTIC ENCLOSURES
WALL MOUNTING ENCLOSURES・FLANGED PLASTIC ENCLOSURES -PDFCATEGORY： WALL MOUNTING ENCLOSURES・FLANGED PLASTIC ENCLOSURES・PLASIC ENCLOSURE WITH FLANGED LID
Specially designed for wall mounting use.
Flanged enclosures, Pole mount enclosures, DIN rail mount boxes are available.
Wall mounting brackets, pole mounting brackets, DIN rail mounting brackets are also available.
Suitable for WiFi access points, IOT sensors, controllers, data loggers, etc.
- IP68 HIGH PERFORMANCE WATERPROOF ENCLOSURE WG series
- IP68 high performance waterproof plastic enclosure.
- Protected from immersion 24 hours at 1m depth.
- Made of UV-resistant ASA material.
- Perfect for use as outdoor gateway / network devices.
- NEW PRODUCT
- IP68 HIGH PERFORMANCE WATERPROOF JUNCTION BOX WG series
- IP68 high performance waterproof junction box.
- Protected from immersion 24 hours at 1m depth.
- Made of UV-resistant ASA material.
- Perfect solution for use as outdoor electrical junction box.
- NEW PRODUCT
- IP68 / IP67 NETWORK PLASTIC BOX - WP series
- IP67 waterproof plastic enclosure. (NEMA 6P rating enclosure)
- Easy pole mounting with optional mounting bracket.
- Suiteble for wireless instruments, LoRa WAN, and access points.
- 24 different selectable sizes are available.
- NEW SIZE
- FLANGED NETWORK PLASTIC BOX - PFF series
- Flat designed plastic enclosure with wall mounting flange.
- Suitable for Wi-Fi access point, IOT gateway, data logger.
- Plastic material : Flame-resistant ABS UL94V-0
- 30 different sizes available for selection.
- NEW SIZE
- FLANGED PLASTIC ENCLOSURE - TWF series
- Multi-purpose flanged enclosure for wall-mount use.
- Made of flame resistant ABS (UL94V-0).
- For wireless network devices, controller, datalogger.
- 23 different sizes in 2 colors.
- NETWORK PLASTIC BOX - PF series
- Flat designed plastic box with detachable panels.
- The most popular electronics plastic enclosure in Japan.
- Made of flame-resistant ABS UL94V-0.
- 36 different sizes in off-white and dark gray colors.
- NEW SIZE
- EMC SHIELDED PLASTIC BOX - PFE series
- EMC shielded version of the PF series network plastic box.
- The inside is coated with conductive paint.
- Suitable for Wi-Fi access point, measuring equipment.
- 4 different sizes are available.
- NEW PRODUCT
- NETWORK PLASTIC CASE - SU series
- Rounded shape design plastic enclosure.
- Suitable for wall-mount communication device usage.
- Snap on / off cover. No screws are required
- 2 different sizes in white and light gray colors.
- PLASTI BOX with HIGED COVER - OP series
- Plastic case with hinged cover.
- General purpose case for wall-mount, desk-top.
- 3 different sizes in light gray and black are available.
- IP67 POLYCARBONATE ENCLOSURE - SPCP series
- Waterproof polycarbonate enclosure for severe environment.
- Protection class : IP67 (equivalent to NEMA6 rating)
- For controller, network devices, outdoor measuring instrument.
- 28 different sizes with 2 different cover types.
- IP67 JUNCTION BOX with KNOCKOUTS - SPCM series
- Waterproof polycarbonate junction box with knockouts.
- Protection class : IP67 (equivalent to NEMA6 rating)
- For junction box, control box, and wireless network devices.
- 21 different sizes with 2 different cover types.
- IP65 LATCH-HINGED ABS PLASTIC BOX - BCAP series
- IP65 waterproof latch/hinged plastic enclosure.
- ABS plastic - Low cost type.
- White gray cover and Transparent cover are available.
- 50 different sizes are available.
- IP65 POLYCARBONATE BOX with KEY LOCK - BCPK series
- IP65 hinged polycabonate enclosure with key lock.
- Made of UL94V-0 and high impact polycarbonate.
- Operating Temperature -20℃～+75℃
- 50 different sizes available.
- FLANGED NETWORK ALUMINIUM ENCLOSURE - MXF series
- Flanged network enclosure with round edge design.
- Made of ABS plastic flanged panel and extruded aluminum.
- For IOT sensor, wireless device, access point and controller.
- 12 different sizes and 8 different color combinations.
- NEW PRODUCT
- IP65 FLANGED ENCLOSURE - EXWF series
- Low cost type waterproof wallmount aluminium enclosure.
- Flanged end panels make it easy for wall mounting.
- Protection class : IP65 / IP54 (Depends on size)
- 67 different sizes in 6 color combinations.
- NEW PRODUCT
- FLANGED ALUMINIUM ENCLOSURE - EXPF series
- Wall mount extruded aluminium enclosure.
- Equipped with flanged frame for easy wall mounting.
- For Network devices, Controllers, Data loggers.
- 67 different sizes, 6 color combinations.
- NEW PRODUCT
- FLANGED EMC SHIELD ENCLOSURE - EXEF series
- EMC/EMI shielded aluminium enclosures with flanged frame.
- Equipped with flanged frame for easy wall mounting.
- For IOT network devices, Measuring instrument, Controllers.
- 67 different sizes in 3 color combinations.
- NEW PRODUCT
- WALL MOUNT Raspberry Pi ACRYLIC CASE - RPA-4B-1F
- Wallmount transparent acrylic Raspberry Pi case.
- Exclusively for use with Raspberry Pi 4 model B.
- Wall mount flange is VESA100 size.
- Can be attached to the back of PC monitors.
- NEW PRODUCT
- VESA MOUNT Raspberry Pi CASE - RPI-F series
- VESA mount Raspberry Pi aluminum case.
- RPI-4B-1F : For Raspberry Pi 4 Model B
- RPI-1F : For Raspberry Pi 2B / 3B / 3B＋
- NEW PRODUCT
- Raspberry Pi DIN RAIL BOX - RPD series
- DIN rail mountable Raspberry Pi 4B enclosure.
- Exclusively for use with 35mm DIN rail.
- Flat shape type and transparent window type are available.
- NEW PRODUCT
- DIN RAIL MOUNTING BASE - DRA series
- DIN rail mounting base for 35mm DIN rail.
- Simple installation and removal via the pull lever.
- Max load : 5kg.
- 3 different sizes available.
- LOW COST DIN-RAIL MOUNTING PLATE - DRT series
- Low cost DIN rail mounting plate for 35mm DIN rail.
- Simple installation and removal by tilting action.
- Max load : 1 kg
- Material : PBT UL94V-0
- DIN RAIL MOUNTING BRACKET - CKD series
- Mounting bracket for 35mm DIN rail.
- Max load : 3kg, Can be easily detached.
- Material : Polyamide
- 3 sizes are available.
- WALL SUSPENSION BRACKET - WM series
- Quick release type wall mounting bracket.
- Easy attachment and removal.
- Large and small brackets in off-white and dark gray colors.
- POLE MOUNTING BRACKET for WG・WGV series
- Pole mount bracket for WG・WGV series.
- Hole milling is not required when installing mount bracket.
- Can be used both for vertical and horizontal installation.
- NEW PRODUCT
- POLE MOUNTING BRACKET - WPMB-M4-3
- Bracket to mount enclosures onto a pole.
- Made from weather resistant ASA material.
- Suitable for both for vertical and horizontal mounting.
- Hole milling is required for bracket installation.
- NEW PRODUCT
- POLE MOUNTING BELT- PKB series
- Universal pole mounting belt for outdoor enclosures.
- Stainless steel type and plastic type are available.
- Use SSK mounting bracket for installation onto a pole.
- POLE MOUNTING BRACKET - SSK series
- Stainless steel pole mount bracket.
- Can be attached to TAKACHI plastic boxes without hole milling.
- Use optional mounting belt to install onto a pole. (PKB series)
- 16 different sizes for variety of enclosures to mount.
- MOUNTING PLATE for OB
- Aluminium mounting plate for OB series.
- Material : Aluminium thickness=1.5mm
- NEW PRODUCT
- WATERPROOF SEALING WASHER SZ series
- Waterproof washer for screwing onto waterproof boxes.
- Oil resistant NBR sealing material on N models.
- Superior water resistant silicone sealing material on S models.
- 8 sizes in M3, M4, M5, M6, M8, M10, M12, and M16.
- PCB MOUNTING SCREW - EM series
- Self tapping screws for PCB bosses on the plastic cases.
- Use them to install your PCB onto bosses on the plastic cases.
- Available for M1.6, M2, M2.3, M2.6, and M3 screws.
- TORX DRIVE SCREW for PLASTIC CASES - MR series
- Hexalobular (TORX) screws for plastic enclosures.
- Fit to CS・CSS・LC・PF・PFF・TW・TWN・TWF series.
- Recommended to be used for tamper resistance.
- TAPPING STANDOFF - TPS series
- Female standoff with tapping screw.
- Easy installation onto existing enclosure boss mount.
- M2.3・M2.6・M3 thread and 4~12mm length are available.
